REGUPOL vibration 480
Vibration isolation
The approved material REGUPOL vibration 480 is used in the load range up to 0.15 N/mm². Depending on load and material thickness, natural frequencies of 10 Hz can be achieved.
REGUPOL vibration 480is a vibration isolation and structure-borne sound decoupling material for the load range up to 0.15 N/mm². It can be used in single or multiple layers to achieve natural frequencies of down to 10 Hz, depending on load and material thickness.
Features
- Approved by building authorities
- Load range up to 0.15 N/mm²
- Natural frequency of down to 10 Hz
- Progressive spring characteristics
- Constant natural frequency over a wide load range
Technical Specifications
Material
PUR-bonded rubber fibres
Dimensions
Length: 10,000 mm, width: 1250 mm,
thickness: 15 mm
Weight per m²
8.6 kg
Downloads
Your contact at REGUPOL
We're here to help.
Acoustic Sales
REGUPOL Australia Pty. Ltd.
Sales Team Australia
REGUPOL – the expert by your side
In REGUPOL, building acoustic specialists all over the world have an expert partner with many years’ experience in vibration isolation and structure-borne sound decoupling of machinery and buildings. The products of the REGUPOL vibration range are characterized by their outstanding durability. Successfully completed projects and expert opinions clearly document the quality of these materials.
