REGUPOL vibration 480

Vibration isolation

REGUPOL vibration 480

Vibration isolation

The approved material REGUPOL vibration 480 is used in the load range up to 0.15 N/mm². Depending on load and material thickness, natural frequencies of 10 Hz can be achieved.

REGUPOL vibration 480is a vibration isolation and structure-borne sound decoupling material for the load range up to 0.15 N/mm². It can be used in single or multiple layers to achieve natural frequencies of down to 10 Hz, depending on load and material thickness.

REGUPOL vibration 480
Cradle to Cradle Certified® Bronze

Features


  • Approved by building authorities
  • Load range up to 0.15 N/mm²
  • Natural frequency of down to 10 Hz
  • Progressive spring characteristics
  • Constant natural frequency over a wide load range

Technical Specifications


Material

PUR-bonded rubber fibres

Dimensions

Length: 10,000 mm, width: 1250 mm,
thickness: 15 mm

Weight per roll

max. 113.0 kg

Weight per m²

max. 9.0 kg
